Multideck Shaking Table
Multideck Lift Type Shaking Table 3 lawj rooj lossis 4 lawj rooj.
Qhov ntev: 4500mm
muaj peev xwm: 0.3-1tph txhua lub lawj
Pub loj: 2-0.022mm.
zog: 1.5kw
Application: For separate gold, silver, tin, columbium, tantalum, titanium, barium, tungsten, iron, chromium, lead, zinc, mercury, copper, etc., and can effectively separation precious and base metals, rare metals and non-metallic minerals.
4 lawj rooj Qhov zoo thiab yam ntxwv
● Its inertial gear structure is ingenious, the vertical component is self-balancing, and the installation is very convenient. It can be installed on the floor of the building or on the bracket.
● Multideck Lift Type Shaking Table is mainly lifting type, vibration reduction, energy saving, low friction consumption, no bulky base, quick and flexible installation.
● Our product uses high-quality FRP decks with a wear-resistant layer, which makes this equipment itself have better wear-resistant, waterproof, and anti-corrosion performance, and has a long service life, which can effectively reduce maintenance and reduce maintenance costs.
● Multideck Lift Type Shaking Table is mainly installed layer by layer, which is very convenient.
● It adopts variable-frequence governor, easily change frequency of stroke to adapt different material with different particle size and feature
● Its biggest feature is that it has a small footprint and can save space, making it very suitable for use in places with limited space.
Txoj Cai Ua Haujlwm:
The shaker sorting is realized under the combined action of the bed surface and the horizontal water flow. The bed strips or grooves on the bed surface are longitudinal and nearly perpendicular to the direction of the water flow. When the water flows horizontally, vortices, eddies and beds are formed in the grooves. The combined effect of surface shaking can loosen the ore layer and layer it according to density. The heavy minerals turn to the lower layer and the light minerals to the upper layer. This process is called "segregation and stratification". The ore particles are subjected to a smaller impulse, so the lateral movement speed of light mineral particles on the bed surface is greater than the lateral movement speed of heavy mineral particles on the bed surface.
4 txheej co lub rooj lub ntsiab technical parameters
Qauv | 3 LOJ | 4 LOJ | |||||
Deck hom | Coarse ore Deck | Cov xuab zeb zoo | Slime Deck | Coarse ore Deck | Cov xuab zeb zoo | Slime Deck | |
Qhov chaw tau txais txiaj ntsig (m2) | 7.6 X 3 | 7.6 X 3 | 7.6 X 3 | 7.6 X 4 | 7.6 X 4 | 7.6 X 4 | |
Deck Loj | Ntev (mm) | 4500 | 4500 | 4500 | 4500 | 4500 | 4500 |
Transmission kawg dav (mm) | 1850 | 1850 | 1850 | 1850 | 1850 | 1850 | |
Concentrate kawg dav (mm) | 1550 | 1550 | 1550 | 1550 | 1550 | 1550 | |
Kev pub mis ntau tshaj (mm) | 2 | 0.5 | 0.074 | 2 | 0.5 | 0.074 | |
Peev xwm (t / h) | 4-5 | 2-3 | 1.5-2.5 | 5-6.5 | 3-5 | 2-3.5 | |
Pub ceev (%) | 20-30 | 18-25 | 15-20 | 20-30 | 18-25 | 15-20 | |
Mob stroke (mm) | 8,10,12,15,18,20,22 | ||||||
Kev mob stroke (r / min) | 270—360（variable-frequence） | ||||||
Kev siv dej (t / h) | 0.7-1 | 0.4-0.7 | 0.4-0.7 | 0.7-1 | 0.4-0.7 | 0.4-0.7 | |
Groove shape ntawm lawj | Muaj Rectangular, Saw- hniav, Daim duab peb sab | ||||||
Lub zog (Kw) | 1.5 kwb | Qhov Loj (mm) | 633024502660 | ||||
4 txheej co rooj sib kis
Daim ntawv thov:
 |  |
| 4 txheej co rooj kub cog nyob rau hauv Russia | 4 txheej co rooj hauv Myanmar |
4 deck shaking table
from JiangXi JiangXi Well{0}}tech International Mining Equipment Co., Ltd
4 layer shaker table for Tungsten plant
Hais txog peb:
FAQ:
Q: Muaj pes tsawg txheej lawj koj tuaj yeem ua tau?
A: Ib txheej / Ob txheej / 3 txheej / 4 txheej lawj tuav lub rooj.
Q:What's capacity for each deack?
A: 0.5tph-1tph txhua lub lawj.
Q:What's the appliation for shaking table.
A: Rau concentration kub, Tin, Tantalum, niobium, titanium, chrome, hlau, manganese, tungsten, Scheelite thiab lwm yam minerals hnyav.
Q: Koj puas tuaj yeem muab cov tshuab cog ua tiav.
A: yog, peb tus kws ua haujlwm yuav ua raws li koj cov ntsiab lus ore thiab yuav tsum tau tsim kom haum tshaj plaws flowchart rau koj.thiab peb tuaj yeem ua tiav tag nrho cov kab cog mining tshuab.
Vim li cas thiaj xaiv peb?
1. We are Manufacturer (Not Dealer):
All machineries from Jiangxi Well-Tech international Mining Equipment Company , with resonable price, good quality and assured full after service. The quality guarantee is 12 months after finishing the trial run of machines which has been shipped to the buyer side. If any part (excluding easily damaging parts) is found defective in quality within warranty period, we would like to replace it for free. After warranty, spare parts can be replaced based on favorable price.
2. Kev Pabcuam Kev cob qhia:
· Peb muab koj nrog cov phiaj xwm prophase, txheej txheem ntws tsim thiab tsim khoom raws li koj qhov kev thov tshwj xeeb.
· Xa cov kws tshaj lij mus rau qhov chaw ua haujlwm rau kev taw qhia kev teeb tsa thiab kev hloov kho, kev cob qhia cov neeg ua haujlwm thiab ua tiav daim tshev thiab lees txais ua ke nrog koj.
· Peb ib txwm khaws qee cov khoom seem ntawm cov khoom seem, uas txhais tau tias cov khoom hloov tuaj yeem xa tuaj rau koj tam sim ntawd.
Xav paub ntxiv, thov hu rau peb, thov xa peb cov lus nug raws li hauv qab no,peb yuav teb koj hauv 24 teev.Thanks for your Attention.
